Model: F18

Professional Fingerprint Access Control Device

General Configuration:

Fingerprint and RFID Identification
Fingerprint Capacity: 3,000
RFID card Capacity(Optional): 3,000
Log Capacity: 30,000
Communication: TCP/IP, RS485/232, USB Host
Access Control Interface for electric lock,door sensor,alarm,exit button.
Wiegand input&output

F18 can connect with Fingerprint and RFID reader to realize anti-passback function.

Ask for price


F18 is an innovated reader for access control application. The device features the fastest commercial-based fingerprint matching algorithm and high-performance, high-image quality infrared detection fingerprint sensor. The device offers flexibility to be installed standalone or with any third party access control panels that support standard Wiegand signal. All the operations can be done on the TFT-LCD color screen. The fingerprint image will be displayed on it. That will guide user to put finger on proper position and increase recognition rate. TCP/IP and RS485 are available that the device can be used in different network.

◆Access Control: Professional Access Control function at high security level
◆Alarm Function: Dismantle Alarm and abnormal door openning alarm
◆2.4” Touch LCD: 2.4″ TFT screen with user-friendly interface
◆Multiple Communication:RS232/485, TCP/IP, USB Host, easy to manage the device
◆USB Communication: Supports USB download and upload of data
◆Embedded Door Bell:Embedded bell and external bell connection
◆Built-in Audio Function: Prompt audio acceptance or rejection for valid or invalid
◆Wiegand Input and output: Can connect with external control panels and slave reader

Display2.4” Inch TFT LCD
SensorZK Latest Optical Fingerprint Sensor
Fingerprint Capacity3,000 pcs
Card Capacity5,000 pcs (Optional)
Logs Capacity100000
AlgorithmZKFinger VX 10.0
Verification SpeedLess than 1s
CommunicationUSB Host, TCP/IP, RS232/485
Access Control Functionsfor 3 rd  Party E-lock, Door Sensor, Exit Button, Anti-Passback, Dismantle Alarm, Doorbell, Webserver
WiegandStand Wiegand input and output
Optional FunctionsID/Mifare/HID
Operating Temperature0 ℃  to 45 ℃   ( -5 °F to 122 °F )
Operating Humidity20% to 80%
Power SupplyDC 12V
Dimension183mm * 80mm * 42mm
Gross WeightAbout 0.82KG
