Description:
The hub from G100 WiFi GSM Home Alarm Kit is a dual network system that utilizes both Wi-Fi 802.11 b/g/n(2.4GHz) and cellular(GSM).
All sensors are wirelessly connected to the hub through RF433 which has strong penetration ability. In the event of alarm activation, for example, when a sensor is triggered, a push notification will be sent and an alarm call will be made automatically to all registered users. The home alarm system can be controlled on-site by the remote controller, or remotely from anywhere with our free dedicated mobile app Smart Life or Tuya Smart.
The hub can connect with up to 100 wireless sensors, 10 remote tags, multiple wireless sirens and an external siren. If the building has lost electrical power, the backup battery built-in the hub provides power operation up to 3 hours.
| Hub | |
| Power Supply | Micro USB 5V 1A |
| Backup Battery | 3.7V, 500mAh Lithium Battery |
| Consumption | <150mA@normal |
| Siren Output | <500mA |
| Radio Frequency | 433Mhz |
| GSM | 850/900/1800/1900MHz |
| Wi-Fi | IEEE802.11b/g/n |
| Operation Temperature: | -10~55℃ |
| Remote | |
| Power Supply | DC 3V (CR2025 Lithium Battery x1) |
| Standby Current | <5uA |
| Transmitting Distance | <80m (Without obstacles and no Interference) |
| Radio Frequency | 433Mhz |
| Operation Temperature | -10~55℃ |
| Door/Window Sensor | |
| Power Supply | DC 3V (CR2032 Lithium Battery x1) |
| Standby Current | <8uA |
| Transmitting Distance | <100m (Without obstacles and no Interference) |
| Radio Frequency | 433Mhz |
| Operation Temperature | -10~55℃ |
| PIR Motion Detector | |
| Power Supply | DC 3V (CR2450 Lithium Battery x1) |
| Standby Current | <15uA |
| Alarm Current | <25mA |
| Detection Scope | <12m/110° |
| Transmitting Distance | <100m (Without obstacles and no Interference) |
| Radio Frequency | 433Mhz |
| Operation Temperature | -10~55℃ |
Click to download realated documents:
G100 WiFi GSM Home Alarm Kit Datasheet
G100 WiFi GSM Home Alarm Kit User Manual
